9600lm Replaceable LED Module CRI80 L80B10 Tools Free Installation

Product Categories

Shenzhen Recolux Lighting Company Limited

Contact Now

9600lm Replaceable LED Module CRI80 L80B10 Tools Free Installation

Model Number : TE85S-60-S1

Certification : ENEC, CE, RoHS, CB

Place of Origin : China

MOQ : Negotiable

Price : Negotiable

Payment Terms : T/T, L/C, Paypal

Supply Ability : 100,000 Pieces per Month

Delivery Time : 3-5 working days for sample, 7-15 working days for mass production

Packaging Details : 8pcs per carton(159*29*22cm)

Input Voltage : 220-240V AC/DC

LED : SMD2835

Input Frequency : 50 or 60 HZ

Lifetime : 50,000(L80B10)

Power Factor : >0.95

Beam Angle : 30°/60°/90°/25°/15°/120°

Switching Cycles : 100,000 times

CRI : Ra>80 or Ra>90

Protection Class : Safety class I

UGR : <23

Driver : Tridonic, Osram, , VS

SDCM : <5

Luminous Efficacy : 160lm/w

Flicker Free : Yes

Emergency : 4W 3H

Sensor : Motion

Dimmable : DALI, 0-10V

Material : Aluminum+PMMA

Warranty : 5 Years

Contact Now

9600lm CRI80 L80B10 Trilux E-line T8 fluorescent replacing led linear module

With LED Luminaire Retrofit you can switch the existing trunking systems without tools and within 44 seconds to LED
Compatible with Trilux E-line T8 trunking systems installed in the past years
Doesn’t need any electrical modifications
Doesn’t need any physical modifications on the existing trunking system
Perfect retrofit solution to replace the old 2x36w, 1x58w and 2x58w T8 tubes with and without reflectors

Datasheet:

Item	Model NO.	Watt	Lumen	Efficacy	Function	EEC	L(mm)
1	TE85S-60-S1	60W-50W-42W-32W	9,000lm	160LM/W	On/off	A++	1495
2	TE85S-60-V1	60W-50W-42W-32W	9,000lm	160LM/W	On/off	A++	1495
3	TE85S-68-PC	68W-60W-54W-48W-38W 32W-25W-20W	10,500lm	160LM/W	On/off	A++	1495
4	TE85S-72-B3	72W-68W-64W-60W-56W-54W-52W-50W-48W-45W	10,500lm	160LM/W	0-10V	A++	1495
5	TE85S-68-T4	Max 68W	10,500lm	160LM/W	DALI	A++	1495

Maximum Loading Of Automatic Circuit Breakers:

	TE85S-60-S1	TE85S-60-V1	TE85S-68-PC	TE85S-72-B3	TE85S-68-T4
B10	12	13	15	15	13
B16	19	21	24	25	21
C10	20	22	25	27	21
C16	32	35	40	42	35

9600lm Replaceable LED Module CRI80 L80B10 Tools Free Installation
FAQ:
Q: What's the best price for my order?

A: Price is based on your order quantity , please contact us to get the best price.

Q: Can I get a sample to check the quality?

A: samples are welcome and it can be delivered to you witin 7 days once you confirmed.

Q: Do you have other similar led light for me to choose?

A: Yes, contact us, we will send more information.

Q: What is the warranty?

A: Most of our products are 5 years warranty.

RECOLUX welcome your inquiry. We will give your best service and best quality goods.
Any questions or doubt. Please feel free to contact us. Welcome to China! Welcome to visit our factory and showroom!
More question pls contact us directly.

For more information, welcome to visit our website www.recolux.com.
